ODIN R4

Are you getting sick of the tiny layouts? Let's meet the Odin!
The design is inspired by the Stora Hammars 1 stone which depicts the Valknut, Odin's cult symbol.
Speaking of Odin, he is the All-Father. He is associated with that is good (wisdom, healing, royalty, knowledge, battle, victory, poetry, a husband to the Goddess Frigg) and the bad (death, the gallows, war, frenzy).
Odin represents the ALL, the EVERYTHING, which is what KBDfans wants to project in a keyboard with a 100% layout.

Text

Changes

- Plate: Default includes 3 plates (Polycarbonate/FR4/Aluminium), still the same price
- PCB: change to 1.6 mm Non-flex cut Hot-swap PCB
- Color options: Pine Green/Mocha/Burgundy three new colors are available

Update

Pre-order after May 29 will ship around begainning of August(2024-07-09)
The new batch of pre-order starts from 2024-05-29 and will be shipped in three months. (2024-05-29)
The pre-order is expected to be shipped around the end of May (2024-03-01)
The pre-order is expected to be shipped in three months, default contains three material plates, added 3 new color options. (2024-02-14)
Odin R3 QC is basically completed, and shipping will start before 2024-01-01.(2023-12-27)
Pre-orders will start shipping progressively around Dec 19th (2023-12-12)
The pre-order case is expected to be shipped in January, 2024 (2023-11-22)
The pre order cases will ship in one month after order placed (2023-10-28)
Start shipping on June 2023 (2023-06-02)
Sale date: May 10th, 2023
The R1 prototype is in production now (2023-04-24)

Specs

Case: Top aluminum, bottom aluminum
Case color: Dark Blue, Dark Purple, E-white, Black, Silver
Wired version PCB: Hot-swap version, Non-Flex cut, without RGB effect, only RGB for Badge, 1.6 mm thickness (Notes: Supports VIA and VIAL. It is recommended to use VIA as VIAL's firmware is not official)
Plate: Polycarbonate/FR4/Aluminum (non-flex cut)
Structure: Leaf spring mount; 100% layout
Interface: USB-C
USB-Port Protector: Aluminum
Translucent badge: Acrylic sandblasting with RGB diffuser
Foams: Case foam, PCB foam, Switch pad (poron material)
Weight Bar: PVD Alu mirrored silver
Rubber feet: Round rubber feet
Typing angle: 7°
Weight: ~1.80kg (with alu weight bar)
~ 2.06kg (after built)
Designer: KBDfans Wei

Optional accessories

Weight Bar: PVD stainless steel mirrored Gold/Laser
Badge: PVD brass Gold/Laser
Wrist rest: Wooden wrist rest
KBDfans handmade custom mechanical keyboard Type-C Cable: Link
Hot-swap assemble service: Link (Please add 100 switches in the cart together)

Include

Aluminum case x1
Aluminum weight bar x1
Aluminum USB port protector x1
Acrylic sandblasting badge x 1
PCB x1
Polycarbonate plate x1
FR4 plate x1
Aluminium plate x1
Case foam x1
PCB foam x1
Switch Pad x1 set
Stabilizer Shims x1 set
Silicone socks x1 set
Screws x1 set
Rubber feet x1 set

Friendly Reminder

The Stabilizers kit and the Type-C Cable are not included in Odin R3 ( please choose 104 kit separately, and Odin R3 does not support Plate mounted stabilizers)
The wooden wrist rest/Badge/Weight bar/Plate of Odin R3 are compatible with Odin V2
The PCB(daughterboard)/Foams of Odin R3 are not compatible with Odin V2
The Badge/Weight bar/Plate/Foams/PCB of Odin R3/V2 are not compatible with Odin V1
Building tutorial: Click

Firmware

Flash manual
Odin V1 Hot-swap: kbdfans_odin_rgb_via.bin odin_rgb.json
Odin V1 Soldered: kbdfans_odin_soldered_via.bin odin_soldered.json
Odin V2, Odin R3: kbdfans_odin V2_rgb_via.bin odin_v2.json
This is not a software update, contact customer service if VIA does not dectect when first plugging in. Keyboards are shipped with preflashed firmware.

Disclaimer

About the case:

1. Keyboard case - If you see any resemblance of marks or foreign material under 2 mm (tool marks, stain, dent, sand mark, scratch, etc.), you're not eligible for Return & Refund.

2. Brass weight - If you see any resemblance of marks or foreign material under 2 mm (tool marks, stain, dent, sand mark, scratch, etc.), you're not eligible for Return & Refund.

3. Case interior - Based on the production method of anodizing and spraying, the product can lead to some smearing at the surface level, and you'll see some hook marks within the case. Also, the spraying process can not guarantee that the color will look 100% the same on the internal case corners. The color off on the interior case and the interior corners are not eligible for Return & Refund.

4. The PVD laser weight and badge have random colors due to the process. Each color will not be exactly the same, there will be different color variations!

Attention:
-Make sure to QC your keyboard case and weight before building it. For any issues besides the three above, please get in touch with our customer support agents to get help.
-For anything built is not eligible for Return & Refund.

Update

The pre-order is expected to be shipped around the end of May (2024-03-01)
The pre-order is expected to be shipped in three months, default contains three material plates, added 3 new color options. (2024-02-14)
Pre-orders will start shipping progressively around Dec 19th (2023-12-12)
The pre-order case is expected to be shipped in January, 2024 (2023-11-22)
The pre order cases will ship in one month after order placed (2023-10-28)
Start shipping on June 2023 (2023-06-02)
Sale date: May 10th, 2023
The R1 prototype is in production now (2023-04-24)

Specs

Case: Top aluminum, bottom aluminum
Case color: Dark Blue, Dark Purple, E-white, Black, Silver
Wired version PCB: Hot-swap version, Non-Flex cut, without RGB effect, only RGB for Badge, 1.6 mm thickness (Notes: Supports VIA and VIAL. It is recommended to use VIA as VIAL's firmware is not official)
Plate: Polycarbonate/Aluminum/FR4 (non-flex cut)
Structure: Leaf spring mount; 100% layout
Interface: USB-C
USB-Port Protector: Aluminum
Translucent badge: Acrylic sandblasting with RGB diffuser
Foams: Case foam, PCB foam, Switch pad (poron material)
Weight Bar: PVD Alu mirrored silver
Rubber feet: Round rubber feet
Typing angle: 7°
Weight: ~1.80kg (with alu weight bar)
~ 2.06kg (after built)
Designer: KBDfans Wei

Optional accessories

Weight Bar: PVD stainless steel mirrored Gold/Laser
Badge: PVD brass Gold/Laser
PCB: 1.6mm Non-Flex cut Hot-swap PCB
Wrist rest: Wooden wrist rest
KBDfans handmade custom mechanical keyboard Type-C Cable: Link
Hot-swap assemble service: Link (Please add 100 switches in the cart together)

Include

Aluminum case x1
Aluminum weight bar x1
Aluminum USB port protector x1
Acrylic sandblasting badge x 1
PCB x1
Polycarbonate plate x1
Polycarbonate plate x1
FR4 plate x1
Case foam x1
PCB foam x1
Switch Pad x1 set
Stabilizer Shims x1 set
Silicone socks x1 set
Screws x1 set
Rubber feet x1 set

Friendly Reminder

The Stabilizers kit and the Type-C Cable are not included in Odin R3 ( please choose 104 kit separately, and Odin R3 does not support Plate mounted stabilizers)
The wooden wrist rest/Badge/Weight bar/Plate of Odin R3 are compatible with Odin V2
The PCB(daughterboard)/Foams of Odin R3 are not compatible with Odin V2
The Badge/Weight bar/Plate/Foams/PCB of Odin R3/V2 are not compatible with Odin V1
Building tutorial: Click

Firmware

Flash manual
Odin V1 Hot-swap: kbdfans_odin_rgb_via.bin odin_rgb.json
Odin V1 Soldered: kbdfans_odin_soldered_via.bin odin_soldered.json
Odin V2, Odin R3: kbdfans_odin V2_rgb_via.bin odin_v2.json
This is not a software update, contact customer service if VIA does not dectect when first plugging in. Keyboards are shipped with preflashed firmware.

Disclaimer

About the case:

1. Keyboard case - If you see any resemblance of marks or foreign material under 2 mm (tool marks, stain, dent, sand mark, scratch, etc.), you're not eligible for Return & Refund.

2. Brass weight - If you see any resemblance of marks or foreign material under 2 mm (tool marks, stain, dent, sand mark, scratch, etc.), you're not eligible for Return & Refund.

3. Case interior - Based on the production method of anodizing and spraying, the product can lead to some smearing at the surface level, and you'll see some hook marks within the case. Also, the spraying process can not guarantee that the color will look 100% the same on the internal case corners. The color off on the interior case and the interior corners are not eligible for Return & Refund.

4. The PVD laser weight and badge have random colors due to the process. Each color will not be exactly the same, there will be different color variations!

Attention:
-Make sure to QC your keyboard case and weight before building it. For any issues besides the three above, please get in touch with our customer support agents to get help.
-For anything built is not eligible for Return & Refund.

Colors

Silver

Dark Purple

E-white

Burgundy

Dark Blue

Mocha

Black

Pine Green

Colors

Dark Purple

Dark Blue

E-white

Black

Silver

Optional accessories

PVD Gold stainless steel weight

PVD Laser stainless steel weight

PVD Gold brass badge

PVD Laser brass badge

Foams

Wooden wrist reset

Features

Compared to the traditional square-corner design, the Odin features a R-corner at the back to give the board a softer and more streamlined profile. The R-corner was also incorporated for your comfort and ergonomics as it makes room for you to slip your fingers underneath for easier moving of the board to so you can get the best typing experience.

To let the board stand out amongst the rest, Odin's Valknut is featured prominently on the front of the board with the RGB logo and in the engraving on the back weight.
